Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number
  • Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis NumberSmallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number
  • Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis NumberSmallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number
  • Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis NumberSmallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number
  • Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis NumberSmallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number

Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number

Luyue CNC Equipment Co Ltd is a large-scale metal engraving machine manufacturer and supplier in China. We have been specialized in Marking machine for many years. Our products have a good price advantage and cover most of the Africa and South America markets. You are welcomed to come to our factory to buy the hot sale, low price, and high-quality Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number. We look forward to becoming your long-term partner.

Send Inquiry

Product Description

As a professional China You are welcomed to come to our factory to buy the hot sale, low price, and high-quality Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number manufacture, you can rest assured to buy Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number from our factory.

LYQD-SC1503A: The smallest and high-accuracy pneumatic handheld marking machine. Potable, light and easy-operating:

LYQD-SC1503A, machine head weighting only 2.6KG, with customized fittings bracket to fit different work piece. With Windows style human-computer interaction operating system, LYQD-SC1503A make the marking process easy and convenient.


High-performance, durable

LYQD-SC1503A could give your product a permanent and durable marking performance. LYQD-SC1503A adopt high precision stepping motor and single guide rail, makes little working noise and high-performance. With stainless steel frame, 22cm*18cm*8cm machine head size and 80mm*30mm - 150mm*30mm marking area, LYQD-1503A could fit most marking pieces and terrible, narrow working environment, especially for the car VIN code.


Abundant marking elements

The operating system support text, matrix, vector graph with the serial, VIN, PIN, VCode, date time, etc coder type to fit different kinds of workers.


Hardware Features

Model LYQD-SC1503A
Marking type Pneumatic handheld
Air pressure 0.2-0.6Mpa
Dimensions 22cm*18cm*8cm
Weight 2.6KG
Power supplier 220V, 50Hz, two-phase power
Marking area 80mm*30mm,130mm*30mm, 150mm*30mm
Marking depth 0.01-0.2mm


Component Features

Stepping motor Digital drive Yamayama, Japan
Guide rail Hiwin, Taiwan, China
Needle Tungsten steel, Japan
Fittings Standard and customized
Solenoid valve America


Hot Tags: Smallest Size 2.6kg Pneumatic Handheld Dot Peen Marking Machine for Chassis Number, China, Manufacturers, Suppliers, Made in China, In Stock, Factory, Factory Directly Sell, Customized, Luyue, Low Price, New Design, Hot Selling, Ready to Ship, Easy-operation, Easy-maintainable
